3D Scanning & Reverse Engineering

3D scanning, used in combination with the Faro measuring arm, allows the scanning of large mechanical elements (up to three metres) with an accuracy of ± 0.15mm. This technique is particularly effective for elements with complex geometries (left surfaces, variable fillets).

By rapidly producing a scatter plot corresponding to the scanned object, it is possible to recreate the corresponding geometries, angles, distances and volumes using reverse engineering.

The digital file of the three-dimensional part can then be used for a dimensional check, to produce a plan drawing or to track the evolution of a mechanical element over time, by comparison with previously acquired scans. This application is particularly useful for assessing the wear of a part according to its use.

Our mechanical engineers can be involved in the process of analysing the results, for example by carrying out a finite element calculation, making technical modifications or estimating residual working life.

Thanks to its experience, HYDRO Exploitation can respond to a large volume of requests for the execution of scanning projects, which can be carried out either in our own workshops or on site.
